RGB+W Five-Pin Controller Module

Description

RGB+W Five-Pin Controller Module

RGB+W Bluetooth & RF Controller allows dual control from a bluetooth app or a back up handheld remote. Controller also includes brake override option which will turn the kit on and to red if it is wired to your positive brake wire as well as a white override function that can be used to turn the kit white with a dome switch or courtesy light. Controller will retain last function if power is removed then applied or placed on a switch. 5 PIN RGB+W STANDARD CONTROLLERAPP "BLEDIM"Allows control of 1 zone, capable of handing up to 12 rock lights and whips or wheel rings. Activation wire for brake & white override.5 PIN 4 ZONE HIGH OUTPUT 30AMP & 50 AMP CONTROLLER **FOR 50 AMP CONTACT US TO SEE IF NEEDED, DOES NOT MAKE BRIGHTER JUST ADS ADDITIONAL CAPACITY**APP "LEDSHOW"Allows 4 separate zones to be independently controlled or linked multiple zones for simultaneous control from the bluetooth app or a back up handheld remote. This high output controller can run up to 40 of our 12w rock lights. We recommend level loading the zones as much as possible. For example if your running 24 lights spread them out over all 4 zones. We don’t recommend more than 10-12 of the 12w on a single zone. Activation wire for brake & white override. 5 PIN 2 ZONE TURN SIGNAL HIGH OUTPUT 30AMP CONTROLLERAPP "LEDSHOW"Allows turn signal functionality with 2 separate zones to be independently controlled or linked multiple zones for simultaneous control from the bluetooth app or a back up handheld remote. This high output controller can run up to 40 of our 12w rock lights. We recommend level loading the zones as much as possible. For example if your running 24 lights spread them out over all 4 zones. We don’t recommend more than 10-12 of the 12w on a single zone. Activation wire for brake, white override, left amber and right amber. Activation wire for brake, white override, left and right turn signal. When turn signal turns on opposite side will turn to white and stay white until turn signal is turned off. 5 PIN BOOSTERDoes not replace controller. Used for long runs of strips or areas where you may see some color drop in systems/installs running large qty’s of lights. Plugs into 12v power and plug in line the system to boost an area. 4 PIN RGB OLDER STYLE CONTROLLERReplaces GEN 1 4 pin RGB controllers. SPECS: -25YR WARRANTY (INCLUDES ACCIDENTAL)-BRIGHTER AND WIDER PATTERN THAN MOST COMPETITORS-PLUG AND PLAY WIRING HARNESS-IP68 WATERPROOF-FULLY MODULAR ADD ON LIGHTS AT ANY TIME EASILY

Vehicle Fitment

Universal fit for every vehicle model currently listed in the UTV Forge catalog.

This item may ship separately. A shipping surcharge is applied automatically in the cart.
